Parameter |
Symbol |
Unit |
Min |
Typ |
Max |
Notes |
|
Transmitter(per Lane) |
||||||
|
Signaling rate per lane |
|
Gbps |
|
25.78 |
|
|
|
Center wavelength |
入c |
nm |
840 |
|
860 |
|
|
RMS Spectral Width |
SW |
nm |
|
|
0.6 |
|
|
Transmit OMA per Lane |
TxOMA |
dBm |
-4 |
|
3 |
|
|
Average Launch Power per Lane |
TXPx |
dBm |
-6 |
|
2.4 |
|
|
Optical Extinction Ratio |
ER |
dB |
2 |
|
|
|
|
Relative Intensity Noise |
RIN |
dB/Hz |
|
|
-128 |
|
|
Optical Return Loss Tolerance |
|
dB |
|
|
12 |
|
|
Average launch power of OFF Transmitter,each lane |
|
dBm |
|
|
-30 |
|
|
Transmitter Eye mask definition {X1,X2,X3,Y1,Y2,Y3} |
|
|
Compliant with IEEE 802.3bm |
Hit ratio 5x10- |
||
|
Receiver(per Lane) |
||||||
|
Signaling rate per lane |
|
Gbps |
|
25.78 |
|
|
|
Center wavelength |
入IN |
nm |
840 |
|
860 |
|
|
Average power each lane |
RXPx |
dBm |
-10.3 |
|
2.4 |
|
|
Rx Sensitivity per lane |
RsENS |
dBm |
|
|
-10.3 |
Note1 |
|
Receiver reflectance |
Rfl |
dB |
|
|
-12 |
|
|
LOS De-Assert |
LOSD |
dBm |
|
|
-13 |
|
|
LOS Assert |
LOSA |
dBm |
-30 |
|
|
|
|
LOS Hysteresis |
|
dB |
0.5 |
|
6 |
|
