Parameter

Unit

Value

Product Type

 (N+1) x 1

Pump Wavelength Range

nm

900 - 1000

Signal Wavelength Range

nm

1064,1550

Fiber Type for Input(Pump Channel)

µm

Nufern 105/125(0.15 NA or 0.22 NA)

Fiber Type for Input(Signal Channel)

µm

PM980, PM1550, PM-6/125 DC or PM-8/125 DC

Fiber Type for Output

µm

PM-10/125 DC or PM-20/125 DC

Max. Signal Channel Insertion Loss

dB

0.5

Min. Signal Channel PER

18

Min. Pump Efficiency

%

98

Max. Input Pump Power

W

6 x 100

Package Dimensions

mm

100(L) x 15(W) x 10(H)

Operating Temperature

℃

-5 to +65

Storage Temperature

℃

-40 to +85
